GE VSCAN AIR CL
GE Vscan Air CL Wireless Ultrasound System’s pocket-sized portability and simplified user interface enable integration into training sessions and examinations in professional healthcare facilities (ex. hospital, clinic, medical office), home environment, road/air ambulance and in other environments described in the product user manual. Vscan Air CL is a wireless, handheld ultrasound system that delivers crystal-clear images. Ideal for abdominal imaging, obstetric, MSK, and more.
Details
- Vscan Air CL Ultrasound System
- Diagnostic ultrasound scanner for mobile use
- Compact and lightweight system that fits comfortably in the hand
- Dual probe technology (convex and linear probe)
- For the examination of superficial and deeper structures
- Console-quality signal processing through state-of-the-art chip
- Exceptional image quality
- For use with Android and iOS devices (Vscan Air App)
- Extremely robust and resistant to drops (MIL-810G) and moisture (IP67)
- Disinfectant resistant
- SignalMax technology
- Battery-operated (scan time: max. 50 minutes)
- For use on adults, children and newborns
Technical Data
- B-mode
- Colour Doppler
- Harmonic Imaging mode
- Convex probe: frequency 2 – 5 MHz, average frequency 3.3 MHz, maximum depth: 24 cm (64 x 16 mm lens)
- Linear probe: frequency 3 – 12 MHz, average frequency 7.7 MHz, maximum depth: 8 cm (40 x 7 mm lens)
- Charging time: approx. 75 minutes
- Protection class: IP67
- High temperature resistance
- Size: 64 x 131 x 31 mm (W x H x D), weight: approx. 205 g
- 2 year warranty
Application
- Thyroid gland
- Abdomen
- Gynaecology/Obstetrics
- Urology
- Thorax/Lung
- Vascular
- Paediatrics
- Cardiology
- Musculoskeletal
Quality imaging capabilities for multiple clinical healthcare applications.
Ideal for OB/GYN, musculoskeletal, abdominal, lungs, and more. Complete both shallow and deep ultrasound scans with one probe without compromising image quality.
Battery Life
- Scan time – up to 50 minutes
- Recharge time – 75 minutes (from 10% to 90%)
- Use any Qi compliant wireless charger
Durabilty
Tested to military drop standards (MIL-810G)2
IP67 rated waterproof2
Compatible with high-level disinfection techniques
Withstands temperature extremes
Data privacy and security
Securely store, share, and collaborate seamlessly. Images and other patient information data are stored in a private, on device space with no access from other apps on the mobile device.
