| Model |
Ti400 |
Ti300 |
Ti200 |
| Temperature |
Temperature measurement range
(not calibrated below -10 °C) |
-20 °C to +1200 °C
(-4 °F to +2192 °F) |
-20 °C to +650 °C
(-4 °F to +1202 °F) |
Temperature measurement
accuracy |
± 2 °C or 2 % (at 25 °C nominal, whichever is greater) |
| On-screen emissivity correction |
Yes (by number and table) |
On-screen reflected background
temperature compensation |
Yes |
| On-screen transmission correction |
Yes |
| Imaging performance |
| Image capture frequency |
9 Hz refresh rate or 60 Hz refresh rate depending upon model variation |
| Detector type |
Focal Plane Array, uncooled
microbolometer, 320 x 240 pixels |
Focal Plane Array, uncooled
microbolometer, 240 X 180 pixels |
Focal Plane Array, uncooled
microbolometer, 200 X 150 pixels |
| Thermal sensitivity (NETD) |
≤ 0.05 °C at 30 °C target temp (50 mK) |
≤ 0.075 °C at 30 °C target temp (75 mK) |
| Total pixels |
76,800 |
43,200 |
30,000 |
| Infrared spectral band |
7.5 µm to 14 µm (long wave) |
| Visual (visible light) camera |
Industrial performance 5.0 megapixel |
| Standard infrared lens type |
| Field of view |
24 ° x 17 ° |
| Spatial resolution (IFOV) |
1.31 mRad |
1.75 mRad |
2.09 mRad |
| Minimum focus distance |
15 cm (approx. 6 in) |
| Optional telephoto infrared lens type, available soon |
| Field of view |
12 ° x 9 ° |
| Spatial resolution (IFOV) |
0.65 mRad |
0.87 mRad |
1.05 mRad |
| Minimum focus distance |
45 cm (approx. 18 in |
| Optional wide-angle infrared lens type, available soon |
| Field of view |
46 ° x 34 ° |
| Spatial resolution (IFOV) |
2.62 mRad |
3.49 mRad |
4.19 mRad |
| Minimum focus distance |
15 cm (approx. 6 in) |
| Focus mechanism |
| LaserSharp™ Auto Focus System |
Yes |
| Advanced Manual Focus |
Yes |
| Image presentation |
| Palettes |
| Standard |
Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted |
| Ultra Contrast™ |
Ironbow Ultra, Blue-Red Ultra, High Contrast Ultra, Amber Ultra, Amber Inverted Ultra,
Hot Metal Ultra, Grayscale Ultra, Grayscale Inverted Ultra |
| Level and span |
Smooth auto-scaling and manual scaling of level and span |
Fast auto toggle between manual
and auto modes |
Yes |
| Fast auto-rescale in manual mode |
Yes |
| Minimum span (in manual mode) |
2.0 °C (3.6 °F) |
| Minimum span (in auto mode) |
3.0 °C (5.4 °F) |
| IR-Fusion ® information |
| Picture-In-Picture (PIP) |
Yes |
| Full screen infrared |
Yes |
| AutoBlend™ mode |
Yes |
| Color alarms (temperature alarms) |
High-temperature , low-temperature, and isotherm (user-selectable) |
| Image capture and data storage |
Image capture, review,
save mechanism |
One-handed image capture, review, and save capability |
| Storage medium |
Micro SD Memory Card, on-board flash memory, save-to-USB capability, direct download via USB-to-PC connection |
| File formats |
Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2) Video*: non-radiometric (MPEG – encoded .AVI) and fully-radiometric (.IS3)
No analysis software required for non-radiometric (.bmp, .jpg and .avi*) files |
Export file formats w/SmartView
software |
BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF |
| Memory review |
Thumbnail view navigation and review selection |
| Other time-saving and productivity features |
| Voice annotation |
60 seconds maximum recording time per image; reviewable playback on imager |
| IR-PhotoNotes™ |
Yes |
| Wi-Fi connectivity |
Yes, to PC, iPhone ® , iPad ® and WiFi to LAN* |
| Text annotation* |
Yes |
| Video recording* |
Standard and Radiometric |
| Streaming Video |
Via USB to PC and HDMI to HDMI compatible screen |
| CNX™ Wireless System* |
Yes* |
| Cardinal Compass* |
Yes* |
| GPS coordinates and recording |
Yes* |
| Auto capture (temperature and interval)* |
Yes* |
AutoRemote control and operation (for
special and advanced applications) |
Yes |
No |
No |
| General specifications |
| Operating temperature |
-10 °C to +50 °C (14 °F to 122 °F) |
| Storage temperature |
-20 °C to +50 °C (-4 °F to 122 °F) without batteries |
| Relative humidity |
10 % to 95 % non-condensing |
Ruggedized Touchscreen
Display (Capacitive) |
8.9 cm (3.5 in) diagonal landscape color VGA (640 x 480) LCD with backlight |
| Controls and adjustments |
User selectable temperature scale (°C/°F)
Language selection
Time/Date set
Emissivity selection
Reflected background temperature compensation
Transmission correction
User selectable hot spot and cold spot, and center point on the image
Expandable-contractable Measurement Box with MIN-AVG-MAX temp
Color alarms
User selectable backlight setting
Graphical information display preference |
| Software |
SmartView ® and SmartView Mobile App – full analysis and reporting software included |
| Batteries |
Two lithium ion rechargeable smart battery packs with five-segment LED display to show charge level, all models |
| Battery life |
Four+ hours continuous use per battery pack (assumes 50 % brightness of LCD and average usage) |
| Battery charge time |
2.5 hours to full charge |
| AC battery charging |
Two-bay ac battery charger (110 V ac to 220 V ac, 50/60 Hz) (included), or in-imager charging. AC mains adapters included. Optional
12 V automotive charging adapter. All models |
| AC operation |
AC operation with included power supply (110 V ac to 220 V ac, 50/60 Hz). AC mains adapters included. |
| Power saving |
User selectable sleep and power off modes |
| Safety standards |
UL 61010-1:2012 CAN/CSA-C22.2 No.61010-1-12 IEC 61010-1 3rd Edition (2010) |
| Electromagnetic compatibility |
EN 61326-1:2006 IEC 61326-1:2005 |
| C Tick |
IEC/EN 61326-1 |
| US FCC |
CFR 47, Part 15 Subpart B Class B |
| Vibration |
0.03 g2/Hz (3.8 grms), 2.5g IEC 68-2-6 |
| Shock |
25 g, IEC 68-2-29 |
| Drop |
Engineered to withstand 2 meter (6.5 feet) with standard lens |
| Size (H x W x L) |
27.7 cm x 12.2 cm x 16.7 cm (10.9 in x 4.8 in x 6.5 in) |
| Weight (battery included) |
1.04 Kg (2.3 lb) |
| Enclosure rating |
IP54 (protected against dust, limited ingress; protection against water spray from all directions) |
| Warranty |
Two-years (standard), extended warranties are available. |
| Recommended calibration cycle |
Two-years (assumes normal operation and normal aging) |
| Supported Languages |
Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified
Chinese, Spanish, Swedish, Traditional Chinese, and Turkish |
