POLYGA H3
The Polyga H3 is a professional handheld 3D scanner with hybrid plug-and-play functionality that is aimed at ease of use, portability, high accuracy, and outstanding speed of data capturing. Like other company’s devices, the H3 is equipped with fast high-resolution cameras providing highly detailed outputs in monochrome or full color, depending on the version purchased. This allows it to produce the highest accuracy in a single-shot scan for a handheld system in its class. Yet one of the main advantages of the scanner is its reasonable price.
The H3 employs structured light technology and proprietary multi-imaging patterns to reconstruct an object as a 3D model that can be further exported to appropriate CAD software. In contrast to other handheld devices, the model shows a noticeable difference in scan quality and level of detail due to its advanced capabilities similar to stationary 3D scanners. Another thoughtful feature is automated scanning with a tripod and rotary table (optional), which does not require additional calibration.
Specifications
| Accuracy | Up to 0.08 mm |
| Software | FlexScan3D |
| Supported file format(s) | PLY, OBJ, STL, ASC, FBX, 3D3 |
| Technology | Structured light, proprietary multi-imaging pattern for 3D capture |
| Cameras | 2 x 700 FPS, monochrome or color option |
| Data acquisition speed | Up to 1.5 million points per second |
| Depth of field | 250 mm |
| Field of view | 205 x 112 to 455 x 252 mm |
| Mesh frames per second | 5 |
| Min. hardware requirements | Windows 10 (64-bit), Intel Core i5 CPU or better, 16 GB memory or greater, 512 MB video card, 250 GB free disk space or more |
| Modes (2-in-1) | Handheld mode, stationary mode (mounted on a tripod) |
| Point-to-point distance | 0.5 mm or better |
| Standoff distance | 380 mm |
| Outer dimensions | 280 x 200 x 60 mm |
| Weight | 1.1 kg |
